Description

Product information:

1. RP2040 microcontroller chip designed by Raspberry Pi
2. Equipped with dual core ARM Cortex MO+processor, the operating frequency reaches 133MHz flexible clock
3. Built in 264KB SRAM and 2MB on-chip Flash
4. The real stamp hole design can be directly welded and integrated into the base plate independently designed by users
5. USB1.1 Host and equipment support
6. Support low power sleep and sleep modes
7. It can be identified by USB as a mass memory for drag and drop downloading
8. The 29 GPIO pins of RP2040 are led out (20 can be led out through pin array, and the rest can only be led out by welding)
9.2 SPI, 2 I2C, 2 UART, 4 12 bit ADC, 16 controllable PWM channels
Precise on-chip clock and timer
Temperature sensor
On chip accelerated floating point library
8 programmable I/O (PIO) state machines for custom peripheral support

Packing list:

Controller development board*1

Specifications

• Weight: 200gr
• Usage: Indoor & outdoor
